60 PCA-6145B/6145L User's Manual
Installing DRAM (SIMMs)
You can use anywhere from 1 MB to 32 MB of DRAM with your
PCA-6145B/PCA-6145L. The card provides one 72-pin SIMM
(single in-line memory module) socket that accepts from 1 to 32
MB DRAM or EDO RAM. The following table shows the bank
assignment for the SIMM socket:
Bank SIMM socket(s) Size
1 SIMM1 72-pin
You can use 256 KBx32, 256 KBx64, 1 MBx32, 1 MBx64, 4
MBx32 or 4 MBx64 DRAM SIMMs.
Memory sizes
The board accepts 1 MB, 2 MB, 4 MB, 8 MB, 16 MB, 32 MB and
EDO RAM. The following table lists some of the different memory
configurations for the PCA-6145B/PCA-6145L card.
SIMM 1 Total
1 MB 1 MB
2 MB 2MB
4 MB 4 MB
8 MB 8 MB
16 MB 16 MB
32MB 32MB
Supported Memory Configurations
