Chapter 1 Hardware Configuration 7
PCA-6145B/PCA-6145L Connectors
Number Function
CN1 Enhanced IDE connector
CN2 LCD connector
CN3 FDD connector
CN4 Parallel port connector
COM1 Serial port 1 connector
COM2 Serial port 2 connector
J1 SBC power connector
J2 VGA connector
J3 Ethernet connector
J4 External Keyboard connector
J5 Keyboard connector
J6 Keyboard lock
J7 Speaker
Safety precautions
Follow these simple precautions to protect yourself from harm and
your PC from damage.
1. To avoid electric shock, always disconnect the power from your
PC chassis before you work on it. Don’t touch any components
on the CPU card or other cards while the PC is on.
2. Disconnect power before making any configuration changes. The
sudden rush of power as you connect a jumper or install a card
may damage sensitive electronic components.
3. Always ground yourself to remove any static charge before you
touch your CPU card. Be particularly careful not to touch the chip
connectors. Modern integrated electronic devices, especially CPUs
and memory chips, are extremely sensitive to static electric dis-
charges and fields. Keep the card in its antistatic packaging when it
is not installed in the PC, and place it on a static dissipative mat
when you are working with it. Wear a grounding wrist strap for
continuous protection.
