Advantech PCA-6145B User Manual

APPENDIX
C
Detailed system
information
This appendix contains information of a
detailed or specialized nature. It includes:
• Parallel connector pin assignments
• HDD connector pin assignments
• FDD connector pin assignments
• Keyboard connector pin assignments
• CRT display connector
• Flat panel display connector
• RS-232 connections
• PC/104 connector pin assignments
• System I/O port address assignments
• System information I/O address
assignments
• DMA channel assignments
• DMA controller registers
• DMA page addresses
• Interrupt assignments
• Timer channel assignments

Advantech PCA-6145B Specifications

General

Brand	Advantech
Model	PCA-6145B
Category	Computer Hardware
Language	English
