Page #70 background image
62 PCA-6145/6145L User's Manual
Parallel/printer connector (CN4)
Pin no. Signal
1 STROBE
2DATA 0
3DATA 1
4DATA 2
5DATA 3
6DATA 4
7DATA 5
8DATA 6
9DATA 7
10 - ACKNOWLEDGE
11 BUSY
12 PAPER EMPTY
13 + SELECT
14 - AUTO FEED
15 - ERROR
16 - INIT PRINTER
17 - SELECT INPUT
18-25 GROUND
HDD connector (CN1)
Pin no. Signal Pin no. Signal
1 - RST 2 GND
3D74D8
5D66D9
7 D5 8 D10
9D410D11
11 D3 12 D12
13 D2 14 D13
15 D1 16 D14
17 D0 18 D15
19 GND 20 N.C.
21 N.C. 22 GND
23 IOW 24 GND
25 IOR 26 GND
