Chapter 4 VGA Display & Ethernet Software/Hardware Configuration 35
45B-STN.BIN (512KB VRAM)
Support 640 x 480 color STN DD 8/16-bit displays
(Sharp LM64C142)
Note: This BIOS does not support simultaneous CRT
and flat panel display with 512KB VRAM.
45B-MONO.BIN
Supports 640 x 480 dual scan monochrome displays
(Sharp LM64P8X/837)
45B-EL.BIN
Supports 640 x 480 EL displays (PLANAR EL640480-A Series)
CBROM.EXE
This program allows you to combine your own VGA BIOS with
the System BIOS.
VGA Display Software Configuration
The PCA-6145B/PCA-6145L’s on-board VGA interface supports a
wide range of popular LCD, EL, gas plasma flat panel displays and
traditional analog CRT monitors. The interface can drive CRT
displays with resolutions up to 1024 x 768 in 256 colors. It is also
capable of driving color panel displays with resolutions of 640 x 480
in 64K colors. The VGA interface is configured completely via the
software utility, so you don’t have to set any jumpers. Configure
the VGA display as follows:
1. Apply power to the PCA-6145B/PCA-6145L with a color TFT
display attached. This is the default setting for the PCA-6145B/
PCA-6145L. Ensure that the AWDFLASH.EXE and *.BIN files
are located in the working drive.
NOTE: Ensure that you do not run AWDFLASH.EXE
while your system is operating in EMM386 mode.
