20 PCA-6751/PCA-6751V User's Manual
2.12 Watchdog Timer PROG (CN10)
For factory pre-setting purposes only.
2.13 VGA Display Connector (CN11)
The PCA-6751/6751V provides a VGA controller for a high resolu-
tion VGA interface. The PCA-6751/6751V's CN7 is a DB-15 connec-
tor for VGA monitor input. Pin assignments for the CRT display are
detailed in Appendix C.
2.14 PC-104 Connectors (CN12)
The PCA-6751/6751V is equipped with a 16-bit ISA signal PC/104
connector for future expansion. Please see Appendix B for details.
2.15 Ethernet Configuration (CN13)
(PCA-6751 only)
The PCA-6751 is equipped with a high performance 32-bit PCI-bus
Fast Ethernet interface which is fully compliant with IEEE 802.3u
100/10Base-T specifications. It is supported by all major network
operating systems.
The medium type can be configured via the Intel82558.EXE program
included on the utility disk. (See Chapter 5 for detailed information.)
RJ-45A connector (CN13)
100/10Base-T connects to the PCA-6751/6751V via an adapter cable
to the RJ-45 standard jack.
Network boot
The network boot feature is built into the BIOS. It can be enabled or
disabled in the chipset setup of the CMOS configuration. Refer to
"BIOS Setting" in Chapter 4 for more information.
