Advantech PCA-6751 Series Manual

Appendix C Pin Assignments 79
C.19 CompactFlash Card Connector (CN24)
Table C-19: CompactFlash card connector
Pin Signal Pin Signal
1 GND 2 D03
3 D04 4 D05
5 D06 6 D07
7 -CS0 8 A10
2
9 -ATA SEL 10 A09
2
11 A08
2
12 A07
2
13 VCC 14 A06
2
15 A05
2
16 A04
2
17 A03
2
18 A02
19 A01 20 A00
21 D00 22 D01
23 D02 24 -IOCS16
25 -CD2 26 -CD1
27 D11
1
28 D12
1
29 D13
1
30 D14
1
31 D15
1
32 -CS1
1
33 -VS1 34 -IORD
35 -IOWR 36 -WE
3
37 INTRQ 38 V
CC
39 -CSEL 40 -VS2
41 -RESER 42 IORDY
43 -INPACK 44 -REG
3
45 -DASP 46 -PDIAG
47 D08
1
48 D09
1
49 D10 50 GND
