Appendix C Pin Assignments
77
C.16
CPU Fan Power Connector (CN19)
T
able C-16: CPU fan power connector
Pin
Signal
1
+5 V
2
GND
3
+12 V
C.17
A
T Power Connector (CN20)
T
able C-17: A
T power connector
Pin
Signal
1
+5 V
2
GND
3
GND
4
+12 V
1234
123
86
88
Table of Contents
