Advantech PCA-6751 Series Manual

Appendix C Pin Assignments 69
C.2 Parallel Port Connector (CN2)
Table C-2: Parallel port connector
Pin Signal
1 \STROBE
2 \AUTOFD
3D0
4 ERR
5D1
6 \INIT
7D2
8 \SLCTINI
9D3
10 GND
11 D4
12 GND
13 D5
14 GND
15 D6
16 GND
17 D7
18 GND
19 \ACK
20 GND
21 BUSY
22 GND
23 PE
24 GND
25 SLCT
26 N/C
13 12 .... 2 1
26 25 .... 15 14
