Advantech PCA-6751 Series Manual

72 PCA-6751/PCA-6751V User's Manual
C.6 36-bit LCD Display Connector (CN6)
Table C-6: 36-bit LCD display connector
Pin Signal Pin Signal
1 GND 2 GND
3 P24 4 P25
5 P26 6 P27
7 P28 8 P29
9 P30 10 P31
11 P32 12 P33
13 P34 14 P35
15 GND 16 GND
17 ENABKL 18 N/C
19 N/C 20 N/C
Note: The model number of the CN6 socket is
DF13A-20DP-1.25V (Hirose Electric Co., Ltd.)
C.7 LCD Power Inverter (CN7)
Table C-7: LCD power inverter
Pin Signal
1 +12 V
2 GND
3 ENABKL
4 VBR
5V
CC
1 3 .... 17 19
2 4 .... 18 20
5 4321
