PCA-6781 User Manual 4

1.3.4 Ethernet interface

! Chipset: Intel 82551QM 10/100Mbps LAN Chip

! Connection: on-board RJ-45 connector

! Interface: IEEE 802.3u (100Base-T) protocol compatible

! Built-in Boot ROM: 82551QM

! I/O address switchless setting

1.3.5 Mechanical and Environmental

! Dimensions (L x W): 185 x 122 mm (7.3” x 4.8”)

! Power Supply Voltage: +5 V

± 5%, +12 V ± 5%

! Power Consumption:

– Max:

2.26 A @ 5 V, 0.5 A @ 12 V

– Typical:

1.22 A @ 5 V (w/Celeron M 1 G + 256 MB RAM)

0.01 A @ 12 V (w/Celeron M 1 G + 256 MB RAM)

! Operating temperature: 0 ~ 60° C (32 ~ 140° F) operation

! Operating humidity: 0% ~ 90% Relative Humidity, non-condensing

Note! If your power supply doesn’t have +12 V output (+5 V only), PCA-6781

needs to go T-part number to add the components for the 5 V to 12 V

converting circuit, but LVDS and PC104 also cannot be used within +5 V

only.
