iii PCA-6781 User Manual

Packing List

Before you begin installing your card, please make sure that the following materials

have been shipped:

! 1 x PCA-6781 series half-sized single board computer

! 1 x Startup manual

! 1 x CD for utility, drivers, and manual (in PDF format)

! 1 x Y cable for PS/2 Keyboard, PS/2 Mouse p/n: 1700060202

! 1 x E-IDE (HDD) cable p/n: 1701400452

! 1 x FDD cable (600 mm) p/n: 1701340705

! 1 x Printer+COM (RS-232) cable w/ bracket p/n: 1700008891

! 1 x ATX power cable 20P/7P 10 cm p/n: 1703070101

! Jumper pack p/n: 9689000002

! 1 x ATX feature cable (3-pin 2.54 mm to 2.0 mm) p/n: 1700002343

! 1 x USB 4 port cable w/ bracket p/n: 1700008887

Optional accessories:

! Audio module with Line-in, Line-out, Mic

p/n:PCM-231A-00A1E

! COM Port Cable without bracket (RS-232/422/485) p/n:1701140201

! Parallel port cable without bracket p/n:1701260301

Power cable for single board usage (Wire 7P/Big 4P x 2 10 cm)

p/n:1700010511

! IDE/SATA Adapter for CPU cards

p/n:PCA-SATAP2-00A1E

If any of these items are missing or damaged, contact your distributor or sales repre-

sentative immediately.

Additional Information and Assistance

1. Visit the Advantech website at www.advantech.com where you can find the lat-

est information about the product.

2. Contact your distributor, sales representative, or Advantech's customer service

center for technical support if you need additional assistance. Please have the

following information ready before you call:

! Product name and serial number

! Description of your peripheral attachments

! Description of your software (operating system, version, application software,

etc.)

! A complete description of the problem

! The exact wording of any error messages
