PCA-6781 User Manual 48

B.1.5 IR Connector (CN5)

B.1.6 LCD Inverter Connector (CN6)

B.1.7 Audio Interface (CN7)

B.1.8 LVDS Connector (CN8)

Table B.5: IR Connector (CN5)

Pin Signal Pin Signal

1+5 V 2 NC

3RX 4 GND

5TX

Table B.6: LCD Inverter Connector (CN6)

Pin Signal Pin Signal

1 +12 V output 2 GND

3 Back-light enable signal

output

4 Back-light VBR signal out-

put

5 +5 V output

Table B.7: Audio Interface (CN7)

Pin Signal Pin Signal

1 +5 V 2 BitCLK

3 Data in 4 GND

5 GND 6 Sync

7 Data out 8 ACRST

9 +5 V 10 SPKR

Table B.8: LVDS Connector (CN8)

Pin Signal Pin Signal

1 GND 2 GND

3 LVDS0_D0+ 4 LVDS1_D0+

5 LVDS0_D0- 6 LVDS1_D0-

7 VDS0_D1+ 8 LVDS1_D1+

9 LVDS0_D1- 10 LVDS1_D1-

11 LVDS0_D2+ 12 LVDS1_D2+

13 LVDS0_D2- 14 LVDS1_D2-

15 LVDS0_CLK+ 16 LVDS1_CLK+

17 LVDS0_CLK- 18 LVDS1_CLK-

19 LVDS power 20 LVDS power
