IST5 Tower UPS 10kVA~40kVA User Manual 9
Installation Instruction
Parallel board
Dry contact
Bypass Input CB
Input CB
Air vent
Connection terminals
Cold start
Output CB
Maintenance
switch
Fig. 2-13 40kVA back appearance
Note
The Standard product is configured with single input; the dual-input option is available, with an
additional breaker for the main input.
