IST5 Tower UPS 10kVA~40kVA User Manual 51
Safety Precautions
7.3 Mechanical Characteristic
Table 7.3 Mechanical Characteristics for Cabinet
Model
Unit
10kL/15kL
10kS/15kS
20S/30S
20L/30L
40kVA
Dimension
W×D×H
mm
250*660*530
250*840*715
350*738*1335
250*680*770
250*836*770
Weight
kg
28
50
88
50
61
Color
N/A
BLACK,RAL 7021
Protection Level
IEC（60529）
N/A
IP20
7.4 Electrical Characteristics
7.4.1 Electrical Characteristics (Input Rectifier)
Table 7.5 Rectifier AC input Mains
）
Item
Unit
Parameter
Grid System
\
3 Phases + Neutral + Ground
Rated AC Input Voltage
Vac
380/400/415
(three-phase and sharing neutral with
the bypass input)
Rated Frequency
Vac
50/60Hz
Input voltage range
Vac
304~478
Vac (Line-Line),full load
228V~304
Vac (Line-Line),load decrease linearly
according to the min phase voltage
Input Frequency range
Hz
40~70
Input Power factor
PF
>0.99
THDI
THDI
％
<3% (full Linear Load)
