30 IST5 Tower UPS 10kVA~40kVA User Manual
Menu name
Menu item
Meaning
alarm
LCD
History log
Display all history logs.
Function
Settings
Display calibration
Adjust the accuracy of LCD display
Date format set
MONTH-DATE-YEAR and YEAR-MONTH-DATE
formats can be selected
Date & Time
Date/Time set
Language set
User can set the language
Communication set
/
Control password 1
set
User can modify control password 1
Command
Battery maintenance
test
This test will lead to the battery being partly discharged
to activate battery until battery voltage is low. Bypass
must be in normal condition, the battery capacity should
be above 25%.
Battery self-check test
UPS transfer to battery discharge mode to test if the
battery is normal. Bypass must be in normal condition,
the battery capacity should be above 25%.
Stop testing
Manually Stop the test including maintenance test,
capacity test
UPS system
information
Monitoring software
version
Monitoring software version
Rectified software
version
Rectifier software version
Inverted software
version
Inverter software version
Serial No.
The serial NO set when delivered from the factory
Rated information
System rated information
Module model
Module model
4.5 Event List
The following Table4.7 gives events of UPS History Log
Table 4.7 List of History Log
String
Sequence
LCD Display
Explanation
1
Load On UPS-Set
Load On UPS
2
Load On Bypass-Set
Load On Bypass
3
No Load-Set
No Load (Output Power Lost)
4
Battery Boost-Set
Charger is Boosting Battery Voltage
5
Battery Float-Set
Charger is Floating Battery Voltage
6
Battery Discharge-Set
Battery is Discharging
7
Battery Connected-Set
Battery cables Connected
8
Battery Not Connected-Set
Battery cables Disconnected.
