Operations
28 IST5 Tower UPS 10kVA~40kVA User Manual
B
A C
I/P MAIN
220.1 V
45.0 A
50.01 Hz
0.99 PF
HOME NEXT
220.1 V
45.0 A
50.01 Hz
0.99 PF
220.1 V
45.0 A
50.01 Hz
0.99 PF
Fig.4-3 Main input page
Select the icon of , it will display the information of battery, as shown in Fig.4-4.
BATTERY P.1
Batt Boost
Dischag Times
10
40
NEXT
HOME
Batt Number
Status
Batt Volt
5.0 A
Batt Curr
240.0 V
240.0 V
5.0 A
Fig 4-4 Battery Information
Select ，to view the current status of the UPS ;
Select ，to turn off the buzzer raising from general alarms;
Select ，to view the system information and maintenance code;
Note
The LCD will go to sleep in 2 minutes during which time if there are no warnings or faults. Press
any button to wake the screen up
