Operations
32 IST5 Tower UPS 10kVA~40kVA User Manual
45
Rectifier Fail-Clear
Incident above disappears
46
Inverter Fail-Set
N# Power Module Inverter Fail
47
Inverter Fail-Clear
Incident above disappears
48
Rectifier Over Temp.-Set
N# Power Module Rectifier Over Temperature
49
Rectifier Over Temp.-
Clear
Incident above disappears
50
Fan Fail-Set
N# Power Module Fan Fail
51
Fan Fail-Clear
Incident above disappears
52
Output Overload-Set
N# Power Module Output Over Load
53
Output Overload-Clear
Incident above disappears
54
Inverter Overload Tout-Set
N# Power Module Inverter Over Load Timeout
55
INV Overload Tout-Clear
Incident above disappears
56
Inverter Over Temp.-Set
N# Power Module Inverter Over Temperature
57
Inverter Over Temp.-Clear
Incident above disappears
58
On UPS Inhibited-Set
Inhibit system transfer from bypass to UPS
(inverter)
59
On UPS Inhibited-Clear
Incident above disappears
60
Manual Transfer Byp-Set
Transfer to bypass manually
61
Manual Transfer Byp-Set
Cancel to bypass manually
62
Esc Manual Bypass-Set
Escape transfer to bypass manually command
63
Battery Volt Low-Set
Battery Voltage Low
64
Battery Volt Low-Clear
Incident above disappears
65
Battery Reverse-Set
Battery pole (positive and negative are reverse)
66
Battery Reverse-Clear
Incident above disappears
67
Inverter Protect-Set
N# Power Module Inverter Protect ( Inverter
Voltage Abnormal or Power Back feed to DC Bus)
68
Inverter Protect-Clear
Incident above disappears
69
Input Neutral Lost-Set
Input Grid Neutral Lost
70
Bypass Fan Fail-Set
Bypass Module Fan Fail
71
Bypass Fan Fail-Clear
Incident above disappears
72
Manual Shutdown-Set
N# Power Module Manually Shutdown
73
Manual Boost Charge-Set
Manually Battery Boost Charge
74
Manual Float Charge-Set
Manually Battery Float Charge
75
UPS Locked-Set
Inhibit to shut down the UPS
76
Parallel Cable Error-Set
Parallel cable in error
77
Parallel Cable Error-Clear
Incident above disappears
78
Lost N+X Redundant
Lost N+X Redundant
79
N+X Redundant Lost-
Clear
Incident above disappears
80
EOD Sys Inhibited
System is inhibited to supply after the battery is
EOD (end of discharging)
