Raising the bobbin thread
Hold the upper thread with the left
hand. Turn the handwheel towards you
(counterclockwise) lowering it, then raise the
needle.
Mark on the handwheel
Note:
If it is diicult to raise the bobbin thread,
make sure the thread is not trapped by the
hinged cover or the sewing table.
Gently pull on the upper thread to bring
the bobbin thread up through the needle
plate hole.
Lay both threads to the back under the
presser foot.
1
1
18
