AEMC 8500 - VT Test Mode Flow Chart

12 Digital Transformer Ratiometer DTR
®
Model 8500
4.3.3 VT Test Mode Flow Chart
Display Indication
for PT/VT Mode
Operator
Action
Comments
Version XXX
©
1999
Chauvin Arnoux
Turn Unit On
Indicates version of
Internal Firmware
AEMC
®
Instruments
DTR
®
Model 8500
N/A
Model Identification
AEMC
®
Instruments
Low Battery
N/A
Replaces Above Indication
when Batteries Need
Recharging
PT/VT Test Mode
N/A
Indication of
Selected Mode
Calibrating
Please Wait
N/A
Internal Calibraiton
in Progress
VT/PT Test Mode
Ready
Push TEST Now
to Initiate Testing
System Ready to
Begin Testing
Press [TEST] to
Check Continuity
Push TEST Now
to Check Continuity
or do nothing to skip
Continuity Test
Option Select
*Ratio Testing
[TEST] to Cancel
Push TEST Now
to Cancel
Te st in Progress
Ratio Testing
in Progress with
Test Cancel Option
Ratio: 60.00 :1
Current: 11 mA
Push TEST Now to
Reset for Next Test
