AEMC 8500 - Control Features

6 Digital Transformer Ratiometer DTR
®
Model 8500
2.2 Control Features
TRANSFORMER RATIOMETER
MODEL 8500
X
H
CHARGING
CONTRAST
TEST
POWER
!
!
R
1 2
8
9
3
4
5
6
7
1. Display
2. BatteryChargeIndicator
3. AC Power Inlet
4. Line Fuse Tray
5. DisplayContrastAdjustment
6. TEST Push button
7. Main Power Switch
8. Low-side“X”cableconnector(secondary)
9. High-side“H”cableconnector(primary)
