Other characteristics and features.
- Internal warning signal indicating a failure in one of the power supplies. If a failure occurs, the
“ALARM” LED on the BC2240 controller board will light up.
- Power feed circuit designed to support hot-swapping operations.
Programming jumpers.
This board has a series of internal programming jumpers (PJ). However, these jumpers are
configured at the factory and, in normal operation, do not need to be changed.
Firmware modules.
At the firmware level, this board is made up of the following modules:
- PIC microcontroller: manages board communications and start-up.
- FPGA programmable device: manages the TDM bus.
The firmware versions can be brought up to date by using the ”BC2000D Firmware Upgrade”
software application.
BC2211 technical specifications.
Synchronism output:
- Type: TTL (Word-Clock).
- Connector: 1.6-5.6 female coaxial.
Coaxial interface:
- Type: 75Ω coaxial.
- Nominal range: 50 m.
- Connectors: 1.6-5.6 female.
- Type of cable: 75 Ω ±2 Ω coaxial, attenuation less than 0.1 dB/m.
Optical fiber interface:
- Type: FDDI PMD.
- Nominal range: 2,000 meters (if your installation entails a range greater than 2000 meters,
contact our sales department).
- Type of fiber: 62.5 / 125 µm MULTIMODE.
- Transmission: LED, 1300 nm.
General characteristics.
- Approximate consumption: 8.5 watts.
- Approximate dimensions:
Front: 17 x 172 mm.
Depth: 255 mm.
- Approximate weight: 310 grams.
Characteristics are subject to change without notice.
