4.4. BC2293. 2x800W Power supply.
General description.
BC2000D system power supply. Delivers up to 800 watts between 1 and 5 48VDC outputs. This
power supply is equipped with two 800-watt converters, one of which is normally operational
while the other serves as a redundant back-up unit. The converters are accessible from the
front panel and can be hot-swapped without having to power down the entire system.
Front Panel Description.
Rear Panel Description.
Uses connectors with SPEAKON type interlock.
Associated with each of the 5 SPEAKON connectors is a fuse carrier holding a 20-Ampere Type
T (timed) protective fuse.
Technical characteristics.
- Power supply: Autoranging, from 90 to 250 VAC, 50/60Hz, with automatic power factor
correction.
- Output voltage: 48 volts DC.
- Maximum power: 800 W.
- Height: 2U.
- Depth: 340 mm.
Characteristics are subject to change without notice.
Two covers give access to the two converters
'PS1' and 'PS2'.
Two LEDs (
