Other characteristics and features.
- Internal warning signal indicating a failure in one of the power supplies. If a failure occurs, the
“ALARM” LED on the BC2240 controller board will light up.
- Power feed circuit designed to support hot-swapping operations.
Programming jumpers.
This board has a series of internal programming jumpers (PJ). However, these jumpers are
configured at the factory and, in normal operation, do not need to be changed.
Firmware modules.
At the firmware level, this board is made up of the following modules:
- PIC microcontroller: manages board communications, as well as board configuration,
alarms and status.
- FPGA programmable device: manages the TDM bus. Two 2Gbps full duplex SerDes
(Serializer / Deserializer) are integrated.
The firmware versions can be brought up to date by using the ”BC2000D Firmware Upgrade”
software application.
BC2213 technical specifications.
Coaxial interface: NON-OPERATIVE.
Optical fiber interface:
- Type: SFP (Small Form Pluggable). Package style duplex LC.
- Nominal range: 150 meters (300 meters for 50/125 µm MULTIMODE fiber).
- Type of fiber: 62.5/125 µm MULTIMODE.
- Transmission: LED, 850 nm.
General characteristics.
- Approximate consumption: 5 watts.
- Approximate dimensions:
Front: 17 x 172 mm.
Depth: 255 mm.
- Approximate weight: 322 grams.
Characteristics are subject to change without notice.
