Other characteristics and features.
- Internal warning signal indicating a failure in one of the power supplies. If a failure occurs, the
“ALARM” LED on the BC2240 controller board will light up.
- Power feed circuit designed to support hot-swapping operations.
Programming jumpers.
This board has a series of internal programming jumpers (PJ). However, these jumpers are
configured at the factory and, in normal operation, do not need to be changed.
Firmware modules.
At the firmware level, this board is made up of the following modules:
- PIC microcontroller: manages board communications and start-up.
- FPGA programmable device: manages the TDM bus.
The firmware versions can be brought up to date by using the ”BC2000D Firmware Upgrade”
software application.
BC2216 technical specifications.
RJ45 interface:
- Ethernet connection for twisted pairs.
- Compatible with IEEE standard 802.3.
- Configurable in 10 base T / 100 base TX.
- Half duplex and full duplex modes.
General characteristics.
- Approximate consumption: 2 watts.
- Approximate dimensions:
Front: 17 x 172 mm.
Depth: 255 mm.
- Approximate weight: 252 grams.
Characteristics are subject to change without notice.
