Other characteristics and features.
- Internal warning signal indicating a failure in one of the power supplies. If a failure occurs, the
“ALARM” LED on the BC2240 controller board will light up.
Programming jumpers.
This board has a series of internal programming jumpers (PJ). However, these jumpers are
configured at the factory and, in normal operation, do not need to be changed.
Firmware modules.
At the firmware level, this board is made up of the following modules:
- PIC microcontroller: manages board communications and start-up.
- FPGA programmable device: manages the TDM bus.
- Digital DSP signal processor: performs signal processing.
The firmware versions can be brought up to date by using the ”BC2000D Firmware Upgrade”
software application.
IMPORTANT NOTE: there are specific firmware versions for each type of board and, besides,
there are different versions depending on the BC 2000 D system working mode as a mixing
console or as a switching matrix.
General characteristics.
- Approximate consumption: 4 watts.
- Approximate dimensions:
Front: 14 x 150 mm.
Depth: 255 mm.
- Approximate weight: 180 grams.
Characteristics are subject to change without notice.
