AM Series Boiler Heat Exchanger Maintenance & Replacement
Technical Instruction Document
Removing the Covers and Initial Disassembly - Continued
5. Remove the plastic blower cover by pulling it from the blower. See Figure 2-7.
6. Pull out the air inlet piece and attached hose from the blower inlet. See Figure 2-7.
Figure 2-7: Removing the Blower Cover & Air Inlet Connector/Hose
2.5: Disconnecting Cables and Wiring Connections
Disconnecting Cables and Wiring Connections
Figure 2-8: Unscrewing Gas Valve Connector & Cutting Harness Cable Tie
1. Unscrew the Phillips head screw from the gas valve connector but leave it plugged in for
now. See Figure 2-8.
2. To the right of the blower, cut the cable tie that ties the cables together. See Figure 2-8.
2
6
5
1
6
Page 9 of 36 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 TID-0137_0A
02/02/2015 Ph.: 800-526-0288
