AM Series Boiler Heat Exchanger Maintenance & Replacement
Technical Instruction Document
5.4: Turning on Services and Leak Testing
Testing for Gas Leaks and Final Assembly
1. Turn ON the gas supply valve. See Figure 5-8.
Figure 5-8: Turn Gas Supply Valve to ON
2. Perform a soap test for leaks on the gas inlet section of the gas valve. Use an appropriate
soap solution, and monitor for the presence of bubbles, which indicate leaks. If leaks are
found, shut off gas, reinstall inlet hardware, and retest. Gas pressures for testing are
according to local or national codes and regulations. See Figure 5-9.
Figure 5-9: Testing with Soap Solution for Leaks (Bubbles)
3. Reinstall the air inlet (and hose) into the left side inlet on the blower. See Figure 5-10.
4. Reinstall plastic blower cover onto the blower by pushing it into place. See Figure 5-10.
Figure 5-10: Installing the Air Inlet Connector/Hose and Blower Cover
SUPPLY
INLET CONN.
INLET CONN.
BLOWER
TID-0132_99 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 Page 33 of 36
Ph.: 800-526-0288 01/18/2015
