Benchmark 6000 Boiler Installation, Operation & Maintenance Manual
APPENDIX G – PART LIST DRAWINGS
Page 174 of 210 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0086_0D
03/20/14 Ph.: 800-526-0288 GF-133
Item #
Qty
Part #
Description
Item #
Qty
Part #
Description
CONTROLS (Continued)
SHEET METAL / PANEL ASSEMBLY
77
2
65120
TERMINAL BLOCK: DIN MOUNTED: BLK
101
4
30117
SIDE PANEL
78
2
65121
TERMINAL BLOCK: DIN MOUNTED: WHT
102
2
35025
SIDE PILLAR
79
3
65122
TERMINAL GROUND BLOCK: DIN
MOUNTED
103
1
30126
TOP PANEL: FRONT
80
2
65118
FUSE TERMINAL: DIN MOUNTED
104
1
30128
PANEL: TOP MIDDLE
81
1
64088
LIMIT CONTROL TEMPERATURE: DIGITAL
CONTROLLER
105
1
30127
PANEL: TOP REAR
82
1
65137
3 POLE 30A BREAKER
106
1
30125
BACK PANEL: RIGHT
83

2
124512
FUSE: 4 AMP
107
1
30124
BACK PANEL LEFT
84 
1
63105
I/O SENSOR/COMM HARNESS
108
1
39174
AIR INLET ADAPTETR
85 
1
63104
I/O INTERLOCK HARNESS
109
8
59133
LATCH: COMPRESSION
86

1
63090
HARNESS ASSY: TEMP LIM CONT PWR
110
1
25078
ASSEMBLY: FRONT PANEL
87
1
124310
TRANSFORMER STEPDOWN 500V/120V
111
2
35024
TOP RAIL
88
1
69161-2
DIN RAIL
112
1
72068
AERCO LOGO
89
1
124324
GROUND BAR
113
1
74024
LOGO: BMK 6000
90

1
63125-1
GAS TRAIN HARNESS
114
2
33148
BRACE: DIAGONAL
91
1
38035
PANEL COVER: I/O BOX
92
1
38036
POWER PANEL COVER
HOSE & INSULATION
93
1
58060
O2 SENSOR
119
1
80084
INSULATION: UPPER
120
2
80083
INSULATION: LOWER
121

1
97005-5
TUBE: FLEXIBLE GAS 18"
OTHER ACCESSORIES / PARTS
127
1
69126
LOW WATER CAPACITY
CUTOFF/CAPACITOR ASSY
129
2
92094
DRAIN VALVE 3/4 NPT
134
1
58067
SAMPLING TUBE KIT
135  1 92084-6
MOTORIZED SEQUENCING VALVE
(OPTIONAL)
 Not shown on drawing
Benchmark 6000 Kits Available
Part #
Description
58066
AIR/FUEL VALVE KIT
58065
BLOWER REPLACEMENT KIT
27086-2
ACTUATOR REPLACEMENT KIT
64106
SSOV W/ REGULATOR KIT
58053-TAB
SPARE PARTS
58067
SAMPLING TUBE KIT
AERCO
International, Inc.
Blauvelt, NY 10913
Benchmark 6000 Part List
02/01/2014
Whole Boiler p/n 28510 (PL-A-178)
Sheet 2 of 8
