EN
11_11. 6755532_02
Placed on high pressure side of cooling circuit, sig-
nals the work pressure to control board, generating a
pre-warning in case abnormal pressure occurs.
Contains the power section and the management of
controls and safety devices. It is in compliance with
the IEC 60204-1 Standard and the Directives regard-
ing electromagnetic compatibility EMC 89/336/CEE
and 92/31/CEE.
Allows the complete control of the appliance.
For a more in-depth description please refer to the
user manual.
Temperature control of the output water with proportional-integral
algorithm: maintains average output temperature at value set
- Self-adapting differential switch: guarantees minimum functioning
times of the compressor in systems with low water content.
- Intelligent defrosting for pressure reduction: allows to determine
when the coil is effectively defrosted, avoiding useless defrosting
- Set-point compensation with external temperature (with external
- Condensation check based on the pressure rather than on tem-
Inverse condensation check for the heat pump functioning mode
- Pre-alarms with automatic reset: in the case of alarm, a certain
number of re-starts are allowed before the definitive block
blocked cycle reversing valve
- Compressor functioning hours count.
- Compressor peak count.
- Historical alarms
- Autostart after voltage drop.
- Local or remote control
Display of the start of the unit:
1. Voltage presence
2. compressor ON/OFF
3.
4.
1. Water outlet
2. water inlet
3.
4. Pressing gas temperature
5. External air temperature (heat pumps, cooling only with DCPX
6.
7.
8.
9.
10. Alarms management:
11. Low pressure
12. High pressure (primary alarm: switch directly blocks supply to
13. High discharge temperature
14.
15.
-
fore blocking.
ON/OFF external contact
Change season from external contact
