TOTAL RECOVERY PERFORMANCE
10.11. WRL140°H°T°°°°°
TOTAL RECOVERY OUTPUT WATER TEMPERATURE °C
25 30 35 40 45 50 55 60
Ph Pe Ph Pe Ph Pe Ph Pe Ph Pe Ph Pe Ph Pe Ph Pe
[kW] [kW] [kW] [kW] [kW] [kW] [kW] [kW]
EVAPORATOR WATER OUTLET TEMPERATURE °C
-8
27.15 6.85 26.77 7.47 26.39 8.17 26.05 8.95 25.81 9.83 ------
-6
29.75 6.85 29.23 7.48 28.71 8.21 28.23 9.04 27.84 9.96 ------
-4
32.35 6.84 31.69 7.50 31.03 8.26 30.41 9.11 29.87 10.07 29.47 11.14 - - - -
-2
34.93 6.85 34.14 7.52 33.35 8.29 32.59 9.18 31.92 10.17 31.38 11.28 - - - -
0
37.50 6.86 36.59 7.54 35.66 8.33 34.77 9.23 33.97 10.25 33.29 11.40 32.80 12.67 - -
2
40.06 6.87 39.02 7.56 37.97 8.36 36.96 9.28 36.02 10.33 35.22 11.50 34.59 12.81 - -
4
42.61 6.90 41.45 7.58 40.28 8.39 39.14 9.32 38.08 10.39 37.15 11.59 36.40 12.93 - -
6
45.15 6.93 43.87 7.61 42.58 8.42 41.32 9.36 40.15 10.44 39.09 11.66 38.21 13.03 37.55 14.55
7
46.42 6.95 45.08 7.62 43.73 8.43 42.42 9.38 41.18 10.46 40.06 11.69 39.12 13.07 38.40 14.61
8
47.68 6.97 46.29 7.64 44.88 8.45 43.51 9.39 42.21 10.48 41.04 11.72 40.04 13.11 39.25 14.66
10
50.19 7.02 48.69 7.68 47.17 8.48 45.69 9.42 44.28 10.51 42.99 11.76 41.87 13.17 40.97 14.74
12
- - 51.08 7.72 49.46 8.50 47.86 9.44 46.35 10.54 44.95 11.79 43.72 13.21 42.71 14.81
14
- - 53.46 7.77 51.74 8.54 50.04 9.46 48.42 10.55 46.91 11.81 45.58 13.24 44.45 14.85
16
- - - - 54.01 8.57 52.21 9.48 50.49 10.56 48.88 11.82 47.44 13.25 46.21 14.87
18
- - - - 56.27 8.61 54.38 9.50 52.55 10.56 50.85 11.81 49.31 13.24 47.98 14.86
10.12. WRL160°H°T°°°°°
TOTAL RECOVERY OUTPUT WATER TEMPERATURE °C
25 30 35 40 45 50 55 60
Ph Pe Ph Pe Ph Pe Ph Pe Ph Pe Ph Pe Ph Pe Ph Pe
[kW] [kW] [kW] [kW] [kW] [kW] [kW] [kW]
EVAPORATOR WATER OUTLET TEMPERATURE °C
-8
31.56 8.06 32.71 8.76 32.42 9.57 30.37 10.49 26.28 11.51 ------
-6
33.65 8.05 34.70 8.78 34.56 9.63 32.91 10.59 29.47 11.66 ------
-4
36.02 8.04 36.87 8.80 36.78 9.68 35.45 10.68 32.58 11.80 27.87 13.04 - - - -
-2
38.64 8.04 39.21 8.82 39.09 9.72 37.99 10.75 35.59 11.91 31.62 13.20 - - - -
0
41.50 8.05 41.71 8.84 41.47 9.76 40.51 10.81 38.51 12.01 35.17 13.35 30.22 14.83 - -
2
44.60 8.07 44.35 8.86 43.92 9.79 43.00 10.87 41.30 12.09 38.53 13.47 34.38 14.99 - -
4
47.93 8.10 47.14 8.89 46.41 9.83 45.46 10.92 43.98 12.16 41.68 13.57 38.25 15.13 - -
6
51.48 8.14 50.05 8.92 48.95 9.86 47.87 10.96 46.52 12.22 44.60 13.65 41.82 15.25 37.87 17.02
7
53.33 8.16 51.55 8.94 50.23 9.87 49.06 10.97 47.74 12.24 45.98 13.68 43.48 15.30 39.94 17.08
8
55.23 8.19 53.09 8.96 51.52 9.89 50.23 10.99 48.92 12.27 47.30 13.71 45.06 15.34 41.92 17.14
10
59.19 8.25 56.23 9.00 54.11 9.92 52.52 11.02 51.17 12.30 49.76 13.76 47.98 15.41 45.55 17.24
12
- - 59.48 9.06 56.72 9.96 54.74 11.05 53.26 12.33 51.97 13.80 50.57 15.46 48.76 17.32
14
- - 62.82 9.12 59.33 10.00 56.88 11.08 55.18 12.35 53.92 13.82 52.80 15.49 51.54 17.36
16
- - - - 61.94 10.05 58.93 11.11 56.91 12.36 55.60 13.83 54.69 15.50 53.88 17.39
18
- - - - 64.53 10.11 60.87 11.14 58.46 12.37 57.00 13.83 56.20 15.50 55.76 17.39
WRL140°H°T°°°°°
WRL160°H°T°°°°°
Data declared according to UNI EN 14511
2008
KEY
Ph Heating capacity
Pe Input power
TOTAL RECOVERY
∆t351015
Cooling capacity - 1 1.01 1.02
Input power - 1 0.99 0.98
Heating capacity -
Changes are
minimal
40
