AERMEC WRL-H - Condenser Useful Static Pressures with Inverter Pump; Evaporator Useful Static Pressures with Inverter Pump

0
1000 2000 3000 4000 5000 6000
7000
0
50
100
130
020I
030I
040I
050I
070I
080I
Water flow rates (l/h)
Useful static pressures [kPa]
CONDENSER USEFUL STATIC PRESSURES WITH INVERTER PUMP
0
1000 2000 3000 4000 5000 6000
0
50
100
120
020I
030I
040I
050I
070I
080I
Water flow rates (l/h)
Useful static pressures [kPa]
EVAPORATOR USEFUL STATIC PRESSURES WITH INVERTER PUMP
If work points are selected
outside of the static pressure
curves range, contact the
head office.
FUNCTIONING IN HEATING MODE
COOLING MODE FUNCTIONING
VERSION WITH INVERTER PUMP “I”
44
IWRLTY. 1201. 5890974_06
