WRL-H VERSION
POWER
SUPP.
U.M. 025H 030H 040H 050H 070H 080H 100H 140H 160H
PROTECTION RATING OF THE MACHINE
IP - - -242424242424242424
ELECTRICAL DATA
Maximum current [FLA]
°
230V-1
A
19,0 22,0 26,0 - - ----
400V-3N 8,5 9,0 11,0 13,0 20,0 23,0 23,0 37,0 43,0
230V-3 - - - 19 23 30 38 46 60
P
230V-1
A
20,0 23,0 27,0 - - ----
400V-3N 10,5 10,0 12,0 16,0 23,0 26,0 24,0 40,0 46,0
230V-3 - - - 22 26 33 42 51 66
Peak current
Without soft-start [LRA]
°
230V-1
A
63,0 84,0 99,0 - - ----
400V-3N 34,0 37,0 50,0 66,0 75,0 75,0 88,0 91,0 94,0
230V-3 - - - 125 155 175 142 175 201
P
230V-1
A
65,0 86,0 101,0 - - ----
400V-3N 36,0 39,0 52,0 70,0 79,0 79,0 90,0 95,0 98,0
230V-3 - - - 128 158 178 146 180 207
Peak current
with soft-start [LRA]
°
230V-1
A
45,0 45,0 45,0 - - ----
400V-3N 24,4 26,5 35,6 46,8 54,1 54,1 67,1 70,1 73,1
P
230V-1
A
45,0 45,0 45,0 - - ----
400V-3N 26,4 28,5 48,1 57,1 57,1 57,1 68,1 73,1 76,1
WATER CONTENT
Evaporator - -
dm3
0.73 0.92 1.23 2.00 2.57 2.95 3.99 5.23 6.18
Condenser - - 0.73 0.92 1.23 2.00 2.57 2.95 3.99 5.23 6.18
MINIMUM SYSTEM WATER CONTENT
Minimum content (standard)
- - l/kW
777777777
Minimum content
[1]
- - l/kW 14 14 14 14 14 14 14 14 14
EXPANSION VESSEL (as per standard in versions with pump/storage tank)
Quantity
P
-n°111111111
Capacity - l 2 2 2 222888
Quantity
A
-n°111111111
Capacity - l 8 8 8 888888
STORAGE TANK (only for versions with storage tank/pumps storage tank)
Quantity - - n° 1 1 1 111111
Tank capacity - - l 100 100 100 100 100 100 150 150 150
SAFETY VALVE (as per standard in all versions)
Quantity - - n° 1 1 1 111111
Calibration - - bar 6 6 6 666666
LOAD (ATTENTION: the declared data can be amended at any time by Aermec, if deemed necessary).
Refrigerant (2 exchangers) - -
Kg
1,1 1,2 1,7 2,0 2,2 2,3 3,2 3,8 4,3
Refrigerant (3 exchangers) - - 1,1 1,3 1,8 2,1 2,3 2,4 3,3 4,0 4,5
Oil - - l 1.1 1.2 1.7 1.7 1.7 1.7 2 x 1.7 2 x 1.7 2 x 1.7
SOUND DATA
Sound power
[2]
-LWdB(A) 55,5 57,0 57,5 59,0 60,0 60,5 62,0 63,0 63,5
Sound pressure [1m]
[3]
-LPdB(A) 41,1 42,6 43,1 44,2 45,2 45,7 46,7 47,7 48,2
Sound pressure [10 m]
[4]
-LPdB(A) 24,3 25,8 26,3 27,7 28,7 29,2 30,6 31,6 32,1
DIMENSIONS
Height °
- mm 976 976 976 1.126 1.126 1.126 1.126 1.126 1.126
Width °
-mm607 607 607 607 607 607 1.157 1.157 1.157
Depth
°-mm628 628 628 798 798 798 798 798 798
DIMENSIONS
Height A
-mm1.126 1.126 1.126 1.126 1.126 1.126 1.126 1.126 1.126
Width A -mm1.157 1.157 1.157 1.157 1.157 1.157 1.757 1.757 1.757
Depth
A-mm798 798 798 798 798 798 798 798 798
WEIGHTS
Weight
°-kg 120 125 130 150 170 180 260 270 280
A-kg 190 200 210 230 250 260 340 350 360
[1]
Minimum content of water in case of process applications, or operating with low load.
[2]
Sound power; Aermec determines the sound power value on the basis of measurements taken in accordance with standard 9614-2, in compliance with
the Eurovent certification.
[3]
Sound pressure in an unrestricted range on a refl ective plane (directional fact. Q=2), 1m away from the unit external surface, complying with ISO 3744.
[4]
Sound pressure in an unrestricted range on a refl ective plane (directional fact. Q=2), 10m away from the unit external surface, complying with ISO 3744.
GENERAL DATA
