COOLING
WRL-H VERSION PUMPS
POWER
SUPPLY
U.M. 025H 030H 040H 050H 070H 080H 100H 140H 160H
COOLING MODE 12/7 - 30/35 °C “FAN COILS”
Cooling capacity
°-
230V-1
kW
6.31 7.92 10.32
------
400V-3N 6.31 8.14 10.43 13.79 17.76 20.28 27.57 35.46 40.51
Total input power °-
230V-1
kW
1.66 1.88 2.39 ------
400V-3N 1.56 1.79 2.26 2.99 4.16 4.87 5.98 8.29 9.70
Total input current °-
230V-1
A
8,50 10,80 13,50 ------
400V-3N 4,20 3,80 5,80 7,20 9,00 10,20 13,30 16,70 19,10
Evaporator water flow rate ° -
230V-1
l/h
1.090 1.360 1.780 ------
400V-3N 1.090 1.400 1.800 2.370 3.055 3.490 4.740 6.100 6.970
System side pressure drops ° -
230V-1
kPa
13 15 20
------
400V-3N 13 16 20 19 22 26 22 29 33
System useful static pressure °
P
230V-1
kPa
69 65 58 ------
400V-3N 69 63 57 85 77 71 154 170 164
N 400V-3N n.d. n.d. n.d. n.d. n.d. n.d. 245 255 249
Condenser water consumption ° -
230V-1
l/h
1'370 1'690 2'190 ------
400V-3N 1'360 1'700 2'180 2'890 3'770 4'325 5'770 7'525 8'635
Condenser side pressure drops ° -
230V-1
kPa
22 22 30
------
400V-3N 22 23 29 29 36 41 37 48 56
Useful static pressure °
B
230V-1
kPa
58 56 45 ------
400V-3N 58 55 46 72 59 50 127 148 137
U 400V-3N n.d. n.d. n.d. n.d. n.d. n.d. 216 233 222
EER - -
230V-1
-
3.81 4.21 4.32 ------
400V-3N 4.05 4.55 4.62 4.61 4.27 4.16 4.61 4.28 4.18
E.S.E.E.R. - -
230V-1
-
4.36 4.85 4.95 - - - - - -
400V-3N 4.66 5.24 5.22 5.20 4.69 4.56 6.07 5.56 5.27
ELECTRICAL DATA: UTILITY SIDE PUMPS
Input power
-P-
kW
0.171 0.175 0.180 0.295 0.317 0.329 0.62 0.85 0.91
- N - n.d. n.d. n.d. n.d. n.d. n.d. 0.95 1.31 1.39
Absorbed current
-P-
A
0.83 0.85 0.87 1.42 1.53 1.59 1.14 1.54 1.64
- N - n.d. n.d. n.d. n.d. n.d. n.d. 1.78 2.62 2.79
Pump useful static pressure
-P-
kPa
82 80 77 104 100 97 176 199 197
- N - n.d. n.d. n.d. n.d. n.d. n.d. 267 284 282
ELECTRICAL DATA: GEOTHERMIC SIDE PUMPS
Input power
-B-
kW
0.174 0.179 0.184 0.312 0.337 0.350 0.67 0.94 1.01
- U - n.d. n.d. n.d. n.d. n.d. n.d. 1.04 1.45 1.55
- I - 0.174 0.179 0.184 0.242 0.261 0.271 n.d. n.d. n.d.
Absorbed current
-B-
A
0.84 0.86 0.89 1.51 1.63 1.69 1.23 1.70 1.82
- U - n.d. n.d. n.d. n.d. n.d. n.d. 1.95 2.90 3.11
- I - 0.84 0.86 0.89 1.17 1.26 1.31 n.d. n.d. n.d.
Pump useful static pressure
-B-
kPa
80 78 75 101 95 90 163 195 192
- U - n.d. n.d. n.d. n.d. n.d. n.d. 251 281 277
- I - 80 78 75 119 120 119 n.d. n.d. n.d.
“SCROLL” COMPRESSORS
N° of compressors / N° of circuits n°/n° 1 / 1 1 / 1 1 / 1 1 / 1 1 / 1 1 / 1 2 / 1 2 / 1 2 / 1
Capacity control %
0 - 100 0 - 100 0 - 100 0 - 100 0 - 100 0 - 100
0-50-100 0-50-100 0-50-100
"PLATE" EXCHANGERS
Heat exchanges - - N° 2 2 2 2 2 2 2 2 2
Hydraulic connections Ø
F / 1”1/4F / 1”1/4F / 1”1/4F / 1”1/4F / 1”1/4F / 1”1/4F / 1”1/4F / 1”1/4 F / 1”1/4
THE DATA DECLARED DO NOT CONSIDER PUMP CORRECTION.
