AERMEC WRL-H - Page 15

HEATING
WRL-H VERSION PUMPS
POWER
SUPPLY
U.M. 025H 030H 040H 050H 070H 080H 100H 140H 160H
COOLING MODE 10/5 - 40/45 °C “FAN COILS”
Heating capacity ° -
230V-1
kW
7.60 9.68 12.16 - - - - - -
400V-3N 7.58 9.17 11.93 15.81 20.04 23.17 31.62 40.08 46.20
Total input power ° -
230V-1
kW
1.98 2.49 3.15 - - - - - -
400V-3N 1.98 2.32 2.92 3.88 4.99 5.83 7.77 9.94 11.67
Total input current ° -
230V-1
A
10.60 13.20 16.60 - - - - - -
400V-3N 4.90 4.90 6.70 8.40 10.60 12.10 15.90 20.30 23.4
Condenser water flow rate ° -
230V-1
l/h
1'310 1'660 2'090 - - - - - -
400V-3N 1'300 1'580 2'050 2'720 3'450 3'990 5'440 6'890 7'950
System side pressure drops ° -
230V-1
kPa
19 19 27 - - - - - -
400V-3N 19 17 26 26 30 35 33 40 48
System side useful static pres-
sure
°
P
230V-1
kPa
62 60 48 - - - - - -
400V-3N 61 62 49 75 67 58 135 157 147
N 400V-3N n.d. n.d. n.d. n.d. n.d. n.d. 224 242 232
Evaporator water consumption ° -
230V-1
l/h
970 1'240 1'550 - - - - - -
400V-3N 960 1'180 1'550 2'050 2'590 2'980 4'100 5'190 5'940
Geo side pressuredrops ° -
230V-1
kPa
11 12 15 - - - - - -
400V-3N 11 11 15 14 16 19 17 20 24
GEO side useful static pressure °
B
230V-1
kPa
72 69 64 - - - - - -
400V-3N 71 70 64 91 86 81 166 180 175
U 400V-3N n.d. n.d. n.d. n.d. n.d. n.d. 258 265 260
I
230V-1 72 68 64 - - - - - -
400V-3N 71 70 64 104 103 100 n.d. n.d. n.d.
C.O.P. ° -
230V-1
-
3.84 3.89 3.86 - - - - - -
400V-3N 3.83 3.95 4.09 4.07 4.01 3.97 4.07 4.03 3.96
ELECTRICAL DATA: USER SIDE PUMPS KIT
Input power
- P -
kW
0.174 0.177 0.182 0.307 0.328 0.342 0.66 0.90 0.97
- N - n.d. n.d. n.d. n.d. n.d. n.d. 1.01 1.38 1.49
Absorbed current
-P-
A
0.84 0.86 0.88 1.48 1.59 1.65 1.20 1.63 1.74
- N - n.d. n.d. n.d. n.d. n.d. n.d. 1.90 2.77 2.98
Pump useful static pressure
-P-
kPa
80 79 76 102 97 93 167 197 194
- N - n.d. n.d. n.d. n.d. n.d. n.d. 256 282 279
ELECTRICAL DATA: GEOTHERMIC SIDE CIRCULATION PUMPS
Input power
-B-
kW
0.170 0.172 0.177 0.283 0.302 0.315 0.59 0.79 0.84
- U - n.d. n.d. n.d. n.d. n.d. n.d. 0.88 1.21 1.29
- I - 0.170 0.172 0.177 0.219 0.234 0.244 n.d. n.d. n.d.
Absorbed current
-B-
A
0.82 0.83 0.85 1.37 1.46 1.52 1.07 1.43 1.52
-U- n.d. n.d. n.d. n.d. n.d. n.d. 1.66 2.43 2.58
-I- 0.82 0.83 0.85 1.06 1.13 1.18 n.d. n.d. n.d.
Pump useful static pressure
-B-
kPa
82 81 79 105 102 100 182 201 199
- U - n.d. n.d. n.d. n.d. n.d. n.d. 275 285 284
- I - 82 81 79 118 119 119 n.d. n.d. n.d.
"SCROLL" COMPRESSORS
N° compressors/N° circuits - - - n°/n°
1 / 1 1 / 1 1 / 1 1 / 1 1 / 1 1 / 1 2 / 1 2 / 1 2 / 1
Flow rate control - - - % 0 - 100 0 - 100 0 - 100 0 - 100 0 - 100 0 - 100 0-50-1000-50-1000-50-100
"PLATE" EXCHANGERS
Heat exchanges - - - N°
222222222
Hydraulic connections - - - Ø F / 1”1/4F / 1”1/4F / 1”1/4F / 1”1/4F / 1”1/4F / 1”1/4F / 1”1/4F / 1”1/4 F / 1”1/4
THE DATA DECLARED DO NOT CONSIDER PUMP CORRECTION.
15
IWRLTY. 1201. 5890974_06
