AERMEC WRL-H - Page 14

HEATING
WRL-H VERSION
POWER
SUPPLY
U.M.
025H 030H 040H 050H 070H 080H 100H 140H 160H
EN14511
HEATING MODE 10/* - 40/45 °C “FAN COILS”
Heating capacity °
230V-1
kW
7.90
9.98 12.64 - - - - - -
400V-3N 7.90 9.51 12.42 16.43 20.91 24.12 32.90 41.90 48.20
Total input power °
230V-1
kW
1.97 2.48 3.15 - - - - - -
400V-3N 1.97 2.31 2.94 3.91 5.05 5.90 7.86 10.12 11.91
Total input current °
230V-1
A
10.55 13.15 16.60 - - - - - -
400V-3N 4.88 4.88 6.75 8.45 10.71 12.24 16.09 20.68 23.89
Condenser water flow rate °
230V-1
l/h
1354 1711 2164 - - - - - -
400V-3N 1354 1631 2127 2813 3578 4125 5627 4158 8224
System side pressure drops °
230V-1
kPa
20 22 29 - - - - - -
400V-3N 20 20 28 28 32 37 35 43 51
Evaporator water consumption °
230V-1
l/h
1371 1685 2186 - - - - - -
400V-3N 1353 1708 2183 2886 3770 4326 5771 7525 8636
Geothermic side pressure drops °
230V-1
kPa
21 23 30 - - - - - -
400V-3N 21 23 30 28 34 40 33 43 51
C.O.P. °
230V-1
-
4.01 4.02 4.01 - - - - - -
400V-3N 4.01 4.12 4.22 4.20 4.14 4.09 4.19 4.14 4.05
THE DATA DECLARED CONSIDER THE PUMP CORRECTION AS ENVISIONED BY THE UNI EN 145111 - 2008 STANDARD.
Attention:
The data declared concern the standard version [
°
]; for different versions, consult the “MAGELLANO” selection program.
COOLING
WRL-H VERSION
POWER
SUPPLY
U.M.
025H 030H 040H 050H 070H 080H 100H 140H 160H
EN14511
COOLING MODE 12/7 - 30/35 “FAN COILS”
Cooling capacity °
230V-1
kW
6.30 7.90 10.29 - - - - - -
400V-3N 6.30 8.12 10.40 13.75 17.70 20.20 27.47 35.30 40.30
Total input power °
230V-1
kW
1.67 1.90 2.42 - - - - - -
400V-3N 1.57 1.81 2.29 3.03 4.22 4.95 6.08 8.45 9.91
Total input current °
230V-1
A
8.57 10.91 13.69 - - - - - -
400V-3N 4.24 3.84 5.89 7.30 9.13 10.38 13.51 17.03 19.52
Evaporator water flow rate
°
230V-1
l/h
1085 1362 1776 - - - - - -
400V-3N 1085 1400 1794 2372 3055 3488 4742 6099 6968
System side pressure drops °
230V-1
kPa
13 15 20 - - - - - -
400V-3N 13 16 20 19 22 26 22 29 33
Condenser water consumption
°
230V-1
l/h
1371 1685 2186 - - - - - -
400V-3N 1353 1708 2183 2886 3770 4326 5771 7525 8636
Condenser side pressure drop
°
230V-1
kPa
22 22 30 - - - - - -
400V-3N 22 23 29 29 36 41 37 48 56
EER °
230V-1
-
3.76 4.16 4.25 - - - - - -
400V-3N 4.01 4.48 4.53 4.53 4.19 4.08 4.52 4.18 4.07
THE DATA DECLARED CONSIDER THE PUMP CORRECTION AS ENVISIONED BY THE UNI EN 145111 - 2008 STANDARD.
Attention:
The data declared concern the standard version [
°
]; for different versions, consult the “MAGELLANO” selection program.
14
IWRLTY. 1201. 5890974_06
