AERMEC WRL-H User Manual

HEATING
WRL-H VERSION
POWER
SUPPLY
U.M.
025H 030H 040H 050H 070H 080H 100H 140H 160H
EN14511
HEATING MODE 10/* - 30/35 °C “RADIANT PANELS”
Heating capacity °
230V-1
kW
8.13 10.16 13.02 - - - - - -
400V-3N 8.06 10.16 12.95 17.09 22.52 25.98 34.23 45.12 51.94
Total input power °
230V-1
kW
1.53 1.91 2.43 - - - - - -
400V-3N 1.52 1.79 2.39 3.06 4.14 4.83 6.17 8.32 9.81
Total input current °
230V-1
A
8.19 10.15 12.80 - - - - - -
400V-3N 3.76 3.78 5.49 6.62 8.79 10.03 12.62 17.00 19.67
Condenser water flow rate °
230V-1
l/h
1393 1741 2229 - - - - - -
400V-3N 1381 1740 2216 2926 3851 4438 5852 7699 8851
System side pressure drops °
230V-1
kPa
21 23 31 - - - - - -
400V-3N 21 23 31 30 37 43 38 50 59
Evaporator water consumption °
230V-1
l/h
1691 2093 2701 - - - - - -
400V-3N 1683 2043 2713 3551 4849 5558 7099 9679 11097
Geothermicside pressure drops °
230V-1
kPa
31 36 46 - - - - - -
400V-3N 32 33 47 43 57 65 50 72 85
C.O.P. °
230V-1
-
5.31 5.31 5.36 - - - - - -
400V-3N 5.30 5.67 5.41 5.59 5.44 5.37 5.55 5.42 5.29
THE DATA DECLARED CONSIDER THE PUMP CORRECTION AS ENVISIONED BY THE UNI EN 145111 - 2008 STANDARD.
Attention:
The data declared concern the standard version [
°
]; for different versions, consult the “MAGELLANO” selection program.
COOLING
WRL-H VERSION
POWER
SUPPLY
U.M.
025H 030H 040H 050H 070H 080H 100H 140H 160H
EN14511
COOLING MODE 23/18 - 30/35 °C “RADIANT PANELS”
Cooling capacity °
230V-1
kW
8.24 10.24 13.24 - - - - - -
400V-3N 8.24 10.05 13.39 17.44 23.84 27.19 34.84 47.51 54.20
Total input power °
230V-1
kW
1.59 1.93 2.47 - - - - - -
400V-3N 1.54 1.83 2.38 3.20 4.35 5.12 6.43 8.76 10.32
Total input current °
230V-1
A
8.15 11.09 13.95 - - - - - -
400V-3N 4.16 3.89 6.11 7.71 9.42 10.72 14.31 17.65 20.32
Evaporator water flow rate
°
230V-1
l/h
1423 1768 2289 - - - - - -
400V-3N 1423 1735 2316 3015 4127 4712 6027 8240 9414
System side pressure drops
°
230V-1
kPa
22 25 33 - - - - - -
400V-3N 22 25 33 31 41 47 36 52 61
Condenser water consumption
°
230V-1
l/h
1691 2093 2701 - - - - - -
400V-3N 1683 2043 2713 3551 4849 5558 7099 9679 11097
Condenser side pressure drops
°
230V-1
kPa
33 33 46 - - - - - -
400V-3N 33 31 46 44 59 67 56 79 93
EER °
230V-1
-
5.18 5.30 5.37 - - - - - -
400V-3N 5.35 5.48 5.63 5.45 5.48 5.31 5.42 5.42 5.25
THE DATA DECLARED CONSIDER THE PUMP CORRECTION AS ENVISIONED BY THE UNI EN 145111 - 2008 STANDARD.
Attention:
The data declared concern the standard version [
°
]; for different versions, consult the “MAGELLANO” selection program.
12
IWRLTY. 1201. 5890974_06
