33
5. Assemble the 8-32 landing gear bolts with flat
washer. Use a drop of blue Loctite on landing
gear bolts before attaching the landing gear.
6. Bolt landing gear strut to fuse with (4) bolts and
washers.
7. Gather the wheel parts as shown below.
(2) wheels, (2) axle assemblies, (4) wheel collars
8. Install axle into pre drilled hole in main landing
gear. Snug tighten only at this time
