44
21. Outer struts have been marked at the bottom to
ensure quick and accurate installation.
Note: Markings may differ from picture
22. Align outer strut with aluminum L brackets and
check for correct fit.
23. Attach outer cabane with 4-40 x 15mm bolts and
#6 flat washers.
24. Secure 4-40 bolts with 4-40 lock nut.
