57
7. Install air vent tube into rubber stopper and bend
upward. Air vent tube should rest as close to the
top of fuel tank as possible. Without touching
the top of the tank.
8. Install the fuel tubing and clunk. Secure the fuel
tubing with nylon ties to the pick-up tube and
clunk.
9. Insert the rubber stopper assembly into the tank
with the vent tube at the top of the tank.
10. Secure the rubber stopper with set screw.
Take care not to strip threads by over tighten
set screw
