68
5. Template shown with both lines drawn ready to
install to fuselage.
6. Remove muffler to make easier installation of
the cowl template.
7. Align center line on template with center mark
on tape you installed before the engine installa-
tion steps.
8. Align 3/8” mark across template with the front
edge of the fuse as shown. Tape template to fuse
To Next Page
