Aeroworks 30cc Freestyle Extra 260 Assembly Manual 49
7. Use the flight control deflection meter (not
supplied) to measure the throws in degrees.
Prop up the tail of the aircraft until the
fuselage is parallel to the table top.
8. Use the widest part of the aileron to measure the
aileron throw in degrees.
9. Use the widest part of the elevator to measure
the elevator throw in degrees.
5. Secure the tabs to the fin using clear tape.
6. Degrees are measured at the tip of the boost tab
as shown below.
