Maintenance
DD+DIS014.02E
Section 12 / 16 ADC Compact Edition 2, Revision 8
(Type 5145 / 100/101/140/200/201/240)
Dust
Fine sharp lines in slow scan
direction on the flat field (see
beside).
· Check if scanner is dusty. In case
of, use the scan-brush to remove
it. Expose another flat field and
compare it again with the sample.
If there are still
unacceptable effects please contact
the Support Center.
Figure 17
5 Completion of Maintenance
(1) Confirm the maintenance by signing the checklist
(2) Make a backup of the system on floppy
(3) Inform the customer about what was done during the maintenance and
which repairs need to be done in next future.
