DD+DIS014.02E
Maintenance
Edition 2, Revision 8 ADC Compact Section 12 / 5
(Type 5145 / 100/101/140/200/201/240)
Evaluation of infocounters.txt
What to check in the
infocounter
Comment
3.3 Hardware
Modification History
By comparing the status of the device with the
available “Modifications”, section 10, the exact
hardware status can be determined.
3.4 Software Modification
History
By checking the software modification history it
can be determined, whether a recent software
upgrade solved a problem, that occurred quite
often in the error list.
4.6 Laser Power If the laser power is under 11 mW, exchange the
laser.
4.7 Galvo Monitoring Check the entries. If the limits of offset (30) or
amplitude (60) are exceeded, check the last
images on the workstation thoroughly for jitter.
Change galvo only if necessary.
5.3 Retries Many retries (> 1%) have to be investigated:
They usually lead to less throughput of the
device. Compare it with frequent error codes.
5.7 Error History Check the last occurred errors (in between two
maintenance), how often they appeared as well
as the CBF (cycles between failures) of these
errors. This gives an overview of the current
status of the machine.
Compare the frequently occurring errors to the
error hit list, section 6.3, and take actions.
5.8 Error List Relatives
and
5.9 Error List Total
Troubleshoot these errors with the help of the
technical documentation, section 6.3,
“Troubleshooting”.
3.1.4 Clear Infocounter
(1) Clear the infocounters to refresh relative counters.
3.1.5 Visual Check
· Flashlight
(1) Check overall condition of the machine – outside and inside – for obvious
changes or damage.
