DR Detector Battery Charger
The battery charger has two slots to insert a battery.
1.
first slot (top)
2.
second slot (bottom)
3.
status indicator for each slot
• Orange to indicate that the battery is charging.
• Green to indicate that the battery is fully charged.
Figure 5: DR Detector Battery Charger
WARNING:
Do not use the battery charger within the patient’s vicinity.
Related Links
Charging a battery on page 91
DX-D 45C, DX-D 45G Battery Charger on page 109
DX-D 45C, DX-D 45G Battery on page 108
Safety directions for the power supply on page 69
DX-D 45C, DX-D 45G | Introduction to the DR Detector | 21
0292B EN 20190401 1627
