System Control Unit Lite
The System Control Unit Lite is connected to the DR Detector via the DR
Detector cable.
The System Control Unit Lite is connected to the X-ray generator to
synchronize the exposure, in a configuration with X-ray generator
synchronization.
The System Control Unit Lite is connected to the workstation via wired
network.
Depending on the configuration, the System Control Unit Lite may not be part
of the system.
1.
Power switch
2.
Status indicator
• Green or orange: ready
Figure 7: System Control Unit Lite
WARNING:
Do not use the System Control Unit within the patient’s vicinity.
Related Links
Safety directions for the power supply on page 70
System Control Unit Lite on page 130
Safety directions for the System Control Unit on page 72
