Labels
Symbol Explanation
On (power: connection to the mains)
On (power: connection to the mains) for part of the
equipment
Off (power: disconnection from the mains)
Off (power: disconnection from the mains) for part of
the equipment
Tube side
Direct current
Alternating current
Protective earth (ground)
Equipotential connector:
Provides a connection between the equipment and the
potential bus bar of the electrical system as found in
medical environments.
It is recommended to use the equipotential connection
as additional safety measure.
This mark indicates that this is a Type B Equipment
Handle with care
Maximum patient weight over the whole area of the
detector surface
Device contains a transmitter module that generates
non-ionizing radiation.
XD 14, XD⁺14 | Introduction to the DR Detector | 41
