DR Detector Switch
The DR Detector Switch is available in the title bar of the MUSICA
Acquisition Workstation. The DR Detector Switch shows which DR detector is
active and shows its status. The DR Detector Switch can be used to activate
another DR detector.
Figure 8: DR Detector Switch
Figure 9: Title bar with DR Detector Switch
Battery status
icon
(empty)
Meaning Full Medium Low Empty
Wired DR Detector
Wireless DR detector is off
or disconnected
Connection sta-
tus icon (wifi/
wired)
(empty)
Meaning Good Low Bad Wired DR de-
tector
DR detector is off
or disconnected
DR Detec-
tor status
icon
(blinking)
(empty)
26 | XD 14, XD⁺14 | Introduction to the DR Detector
