Table 1: Skull AP portrait
R
AP
R
1 2 3
Figure 18: Skull AP portrait
1. Detector orientation (Portrait)
2. Patient orientation (AP)
3. Result on monitor
Table 2: Chest PA Landscape
R
PA
R
R
1 2 3
5
Figure 19: Chest PA landscape
1. Detector orientation (Landscape)
2. Patient orientation (PA)
3. Result on monitor
Table 3: Table with bucky
Table with bucky, portrait
