Using and Updating the Logic Analysis System 6
16900 Series Logic Analysis Systems Installation Guide 101
To locate specifications and characteristics
Electrical and Operating Environment Characteristics
The following operating characteristics are not specifications, but are
typical operating characteristics for the Agilent 16900 Series logic analysis
systems.
Trigger In
The Trigger In connector is 5.5V Max pk and DC, CAT I (line isolated).
Clock In
The Clock In connector is 5.5V Max pk and DC, CAT I (line isolated).
Electrical Characteristics
Power
Requirements
Frame(16900/902A): 115/230 Vac +/- 20%, 48-66Hz, 1300W Max
Frame(16902B): 100/240 Vac, 47-63Hz, 1300W Max
Frame(16903A): 115/230 Vac +/- 20%, 48-66Hz, 900W Max
Frame(16901A): 115/230 Vac +/- 20%, 48-66Hz, 775W Max
CAT II (Line voltage in appliance and to wall outlet)
Pollution degree 2
Environmental Characteristics (Operating)
Temperature Instrument (16900A, 16902A, 16902B): 0° to + 40° C (+32° to +104° F)
Instrument (16903A): 0° to + 50° C (+32° to +122° F)
Instrument (16901A): 0° to + 45° C (+32° to +113° F)
Disk Media: 10° to + 40° C (+50° to +104° F)
Probes/cables: 0° to + 65° C (+32° to +149° F)
Altitude 3,000 m (10,000 ft)
Humidity Relative humidity 8 to 80% at 40° C (104° F). Avoid sudden, extreme
temperature changes which could cause condensation on the circuit
board.
For indoor use only.
